RB760iGS
EL hEX S es un router con cinco puertos Ethernet Gigabit, para lugares donde la conectividad inalámbrica no es requerida. Comparado con el hEX, el hEX S también incluye un puerto SFP y salida PoE en su último puerto.
Es asequible, pequeño y fácil de usar, pero al mismo tiempo viene con un poderoso CPU de doble núcleo de 880 MHz, y 256 MB de RAM, capacitado para todas las configuraciones avanzadas que RouterOS incluye. El dispositivo tiene un puerto USB 2.0, salida PoE en el puerto Ethternet #5, y un gabinete 1.25 Gbit/s.
El cifrado IPsec y el servidor Dude están incluidos, el puerto microSD provee una velocidad r/w mejorada para almacenaje de información y el Dude.
Especificaciones del producto
| DETAILS |
|---|
| Product code | RB760iGS |
| Architecture | MMIPS |
| CPU | MT7621A |
| CPU core count | 2 |
| CPU nominal frequency | 880 MHz |
| CPU Threads count | 4 |
| Dimensions | 113 x 89 x 28 mm |
| License level | 4 |
| Operating System | RouterOS |
| Size of RAM | 256 MB |
| Storage size | 16 MB |
| Storage type | FLASH |
| Tested ambient temperature | -40°C .. 70°C |
Alimentación
| DETAILS |
|---|
| Max Power consumption | 11W |
| PoE in | 802.3af/at |
| PoE out | Passive PoE up to 57V |
| PoE in input Voltage | 12-57 V |
| Number of DC inputs | 2 (DC jack, PoE-IN) |
| DC jack input Voltage | 12-57 V |
Ethernet
| DETAILS |
|---|
| 10/100/1000 Ethernet ports | 5 |
Fibra
Periféricos
| DETAILS |
|---|
| Number of USB ports | 1 |
| USB Power Reset | Yes |
| USB slot type | USB type A |
| Max USB current (A) | 1 |
Otros
| DETAILS |
|---|
| PCB temperature monitor | Yes |
| Voltage Monitor | Yes |
