EB104 Pressure Button

EB104-G | Open button type fungus contact no / com

The EB104 is a new mechanical push switch made of aluminium. It is characterized by its small size, elegant appearance, economic application and high value ratio. It is used in the field of access control security, electronic access control systems, etc.

• Parameters Switch voltage CC 12 ~ 24 V
• Nominal current 5A
• Operating temperature -20 ° C ~ + 50 ° C
• Storage temperature -20 ° C ~ + 65 ° C
• Working humidity 10% - 90%
• Buck mode Incorporated reducing converters
• Method of operation Self-replication
• IK10 explosion-proof
• 4 mm aluminium plate housing material
• Surface treatment
• Printed black characters + vertical drawing
• Dimension 86 mm x 86 mm x 38,5 mm (long x wide x high)

DANGES

• → Technical information sheet
